Motherboard ASUS H61 MK - Socket 1155 DDR2

Motherboard ASUS H61 M K Socket 1155

Compatibility
Intel Socket 1155 for 3rd/2nd Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors
Supports Intel 22 nm CPU
Supports Intel 32 nm CPU
Supports Intel Turbo Boost Technology 2.0
Supports CPU up to 77 W
* The Intel Turbo Boost Technology 2.0 support depends on the CPU types.t

Chipset
Intel H61(B3)

Memory
Dual Channel Memory Architecture
* 1600MHz and higher frequency is supported by Intel 3rd generation processors.
* Due to OS limitation, when installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Install a 64-bit Windows OS when you want to install 4GB or more memory on the motherboard.

Graphic
Integrated Graphics Processor
Multi-VGA output support : DVI/RGB ports
- Supports DVI with max. resolution 1920 x 1200 @ 60 Hz
- Supports RGB with max. resolution 2048 x 1536 @ 75 Hz
Maximum shared memory of 1024 MB

Expansion Slots
1 x PCIe 3.0/2.0 x16 *1
2 x PCIe 2.0 x1

Storage
Intel H61(B3) chipset :
4 x SATA 3Gb/s port(s), blue

LAN
Realtek 8111F, 1 x Gigabit LAN Controller(s)

Audio
Realtek ALC887 8-Channel High Definition Audio CODEC *2

USB Ports
Intel H61(B3) chipset :
8 x USB 2.0 port(s) (4 at back panel, black, 4 at mid-board)


Weight : 1500 grm
